Event Notification Overview

Event Notification feature is designed to provide information about changes on Yeastar P-Series Software Edition and helps you monitor operations on the PBX. When an event occurs, the system will record the event and notify contacts concerned via specific methods. This topic describes event types, event levels, notification methods, notification email templates, and auto cleanup of events.

Event types

Yeastar P-Series Software Edition supports the following event types:

Table 1. Operations
Event Description
Administrator Login Success The administrator successfully logged in to the PBX management portal.
Web User Login Success A user successfully logged in to the PBX web portal or the Linkus Web Client.
Web User Login Failed A user failed to log in to PBX web portal or the Linkus Web Client.
Linkus Client Login Failed An extension user failed to log in to Linkus Mobile Client or Linkus Desktop Client.
Administrator Password Changed The administrator's password was changed.
Extension User Password Changed An extension user's user password was changed.
RPS Request Success The RPS request of the IP Phone(s) succeeded.
RPS Request Failed The RPS request of the IP Phone(s) failed.
Table 2. Telephony
Event Description
SIP Trunk Registration Failed Failed to register or connect to a SIP trunk.
SIP Trunk Re-registered Successfully re-registered or re-connected to a SIP trunk.
Emergency Call Dialed Out An extension user placed an emergency call.
Table 3. System
Event Description
CPU Overload CPU ran over 90% in 10s.
Memory Overload Memory ran over 90% in 10s.
Storage Device Failure Failed to write data to storage device.
Insufficient Storage The storage ran out of 90%.
Lost Connectivity to Storage Device Lost connection to storage device.
Auto Cleanup Reminder Reach 90% of the allowed storage limit.
System Reboot Either of the following situations triggered the event:
  • The PBX rebooted after configuration.
  • The PBX automatically rebooted after system crash.
System Restore The PBX was restored.
New System Firmware Detected The PBX automatically detected a new firmware version.
System Upgrade Completed The PBX was upgraded.
PBX Hot Standby Failover A PBX failover has occurred, and the PBX system is taken over by the other server.
Primary Server Data Restoration Completed The Primary Server is fixed and the data synchronization is completed now.
Both PBX Servers Failed to Function Both the Primary Server and the Scondary Server of your PBX system were down.
Data Synchronization Error Due to Server Missing The data synchronization could not function properly as the opposite PBX server is not detected.
Yeastar SMTP Server Error Yeastar SMTP server failed to send emails.
Abnormal License Activation Failed to connect to extranet License Activation Server.
Data Synchronization Error Due to Storage Missing The data synchronization could not function properly as the storage device of the opposite PBX server is not detected.
SD-WAN Network Joined Successfully A PBX has successfully joined the SD-WAN network.
SD-WAN Network Exited A PBX has exited the SD-WAN network.
SD-WAN Network Disconnected A PBX has lost connection to the SD-WAN network.
SD-WAN Network Connection Switched The Secondary Server in a Hot Standby pair has joined the SD-WAN network as it takes over the phone system from the Primary Server.
Abnormal Working Server The Working Server is abnormal and the Redundancy Server will take over the telephony services.
Abnormal Redundancy Server The Redundancy Server is abnormal, you need to fix the issue as soon as possible.
Disaster Recovery Fallback A disaster recovery fallback was triggered and the Redundancy Server has taken over the telephony services.
Disaster Recovery Data Synchronization Error The data synchronization between the Working Server and the Redundancy Server encounters an error.
Working Server Data Restoration Completed The Working Server is repaired and the data synchronization from Redundancy Server is completed.
Abnormal Core Call Services A deadlock issue has been detected in the core call process.
Core Call Services Recovery Completed The core call process has recovered successfully.
Table 4. Security
Event Description
Web User Locked Out PBX blocked the source IP when either of the following situations was met:
  • Web Login failure for more than 5 times in 24 hours.
  • More than 5 accounts were locked in 24 hours.
Linkus User Blocked Out PBX blocked the source IP when either of the following situations was met:
  • Login failure (Linkus Mobile Client or Linkus Desktop Client) for more than 5 times in 24 hours.
  • More than 5 accounts were locked in 24 hours.
Extension Registration Blocked Out PBX blocked the source IP when either of the following situations was met:
  • Registration failure for more than 20 times.
  • More than 3 accounts were locked.
Auto Defense IP Blocked Out The monitored service or port reached the limit of Number of Packets during specific Time Interval.
Outbound Call Frequency Exceeded An extension has exceeded the limit of Number of Calls during specified Time Period set in an Outbound Call Frequency Restriction rule.
Outbound Call to a Disallowed Country An extension user made an outbound call to a disallowed country.
API Authentication Blocked Out PBX blocked the source IP due to too many failed API authentication attempts.
Linkus SDK Authentication Blocked Out PBX blocked the source IP due to too many failed Linkus SDK authentication attempts.
Table 5. Reminder
Event Description
Video Conferencing Usage Has Reached 90% of Time Limit Reach 90% of the annual time limit of video conferencing.
Video Conferencing Usage Limit Reached Reach annual usage limit of video conferencing.
License Expiration Reminder The current license will expire soon.
Failed to Archive File(s) The task to archive recording files or backup files to an external server has failed.

Event levels

Event level is used to indicate how severe or important an event is. Choosing an appropriate level prevents recipients from receiving repetitive information.
Yeastar P-Series Software Edition supports the following event levels:
  • Information: Events that pass general information to recipients.
  • Warning: Events that indicate specific components or applications are not in ideal states, and further action could result in errors.
  • Alert: Events that indicate problems require timely attention.
    Note:
    • When an event occurs, the system gives you a pop-up reminder on the right of PBX web portal.
    • For event whose default level is not Alert, the system will NOT give you a pop-up reminder even if you change the level from Information or Warning to Alert.

Notification contacts and methods

You can set notification contacts to internal users or external users, and notify users in the following ways when events occur:
  • Send Email
  • Call Extension
  • Call Mobile

For more information, see Manage Notification Contacts.

Notification email templates

If notification method is set to Send Email for a specific contact, the system will send notification emails in corresponding email template when an event occurs. Yeastar P-Series Software Edition provides default email template for each event, you can also customize email templates according to your needs.

For more information, see Customize Email Templates.

Auto cleanup of event logs

By default, when event logs reach 50,000, the system automatically deletes the oldest logs. You can change the value, or set the maximum days that logs can be retained.

For more information, see Auto Cleanup Settings.
