System Preferences
This topic describes the preference settings that will be applied globally to Yeastar P-Series PBX System.
Go to
to configure preferences settings.Basic preferences
Setting | Description |
---|---|
Device Name | Set a name for the PBX. The name will be used as the sender name when PBX sends emails out. |
Name Display Format | Set display format for extension user's name and contact's
name.
|
Max Call Duration (s) | Set the global maximum call duration for an active call. When
the call duration reaches the limit, the call will be ended. The
default value is 10800. Note: For outbound calls, the Max Call Duration
(s) setting of the caller's extension
takes precedence.
|
FXO Mode |
Select a mode to set the On Hook Speed, Ringer Impedance, Ringer Threshold, Current Limiting, TIP/RING voltage, adjustment, Minimum Operational Loop Current, and AC Impedance as pre-defined for your country's analog line characteristics. |
Tone Region | Select your country or the nearest neighboring country to enable the default dial tone, busy tone, and ring tone. |
Flash-Hook Event | Set which event will be triggered by pressing the hook flash.
|
Virtual Ring Back Tone | If enabled, when the caller calls out via cellular trunk, the caller will hear the virtual ring back tone generated by the system before the callee answers the call. |
Organization Management
Setting | Description |
---|---|
Organization Management | If enabled, you can arrange extension users into organizations. |
Company Name | Set your company name, which will be used as the root organization name. |
Internal Chat
Setting | Description |
---|---|
Internal Chat | The option is enabled by default. If disabled, extension
users will NOT be able to access and use the internal chat
feature (Instant Messaging, IM) on their Linkus UC clients. Note: The Linkus UC clients that can apply
this setting are as listed below:
|
Distinctive Caller ID Name
Setting | Description |
---|---|
Display Call Feature Name | If enabled, the Caller ID will display the originated name when users receive a call from a ring group, queue, and IVR. |
Display DID/DDI Name | If enabled, the Caller ID will display the DID name of the source trunk. |
Masked Number
Specify the scenario(s) where external number will be masked. Once enabled, the number displayed in the call window and call logs will be masked.
Note:
- The masking rule applies when receiving and making calls using IP phones, softphones, or Linkus UC Clients. However, when using analog phones, the external numbers will not be masked.
- If the external number is shorter than 6 digits, it will not be masked.
- Callback to a masked number is not allowed.
Setting | Description |
---|---|
Calls initiated via "Open API" | If enabled, destination number will be masked when a third-party application initiates external calls through the API interface. |
Calls initiated via "Speed Dial" | If enabled, destination number will be masked when extension users make external calls through Speed Dial. |
Calls initiated via "Click to Call" | If enabled, when extension users initiate calls via
click-to-call using 'Yeastar Linkus for Google' Chrome
extension, destination number will be masked. Note: The version of the Chrome extension
must be 4.11.1 or later. |
Incoming Calls | If enabled, external numbers will be masked when extension users receiving inbound calls. |
DTMF preferences
Setting | Description |
---|---|
DTMF Passthrough | If enabled, PBX will pass DTMF tones directly to the other end without processing the DTMF tones. |
DTMF Duration (ms) | Set the duration (in millisecond) of DTMF audio signal sent by the PBX. The default value is 120. |
DTMF Gap (ms) | Set the interval (in millisecond) between two DTMF audio signals sent by the PBX. The default value is 120. |
Extension preferences
Below are default extension ranges. You can change the extension range according to
your needs.
Note: PBX treats the followings as extensions. Extension users can dial
extension numbers to reach them directly.
Extension Type | Default Range |
---|---|
User Extension | 1000 - 5999 |
Parking Extension | 6000 - 6099 |
Group Voicemail Extension | 6100 - 6199 |
IVR Extension | 6200 - 6299 |
Ring Group Extension | 6300 - 6399 |
Queue Extension | 6400 - 6499 |
Conference Extension | 6500 - 6599 |
Paging Extension | 6600 - 6699 |
Account Trunk | 6700 - 6799 |
WebRTC Trunk Number | 6800 - 6899 |
